LEDSAT Satellite

Spacecraft LEDSAT (LED-based Satellite)
Spacecraft type CubeSat
Units or mass 1U
Status Operational (IAC 2022 paper last checked on 2022-12-26)
Launched 2021-08-17
NORAD ID 49069
Deployer PSL / PSL-P (Picosatellite Launcher) [Astrofein]
Launcher Vega (VV19)
Organisation Sapienza University of Rome
Institution University
Entity Academic / Education
Headquarters Italy
Partners The Sapienza Space Systems and Space Surveillance Laboratory (S5Lab)

Equipped with LEDs and retroreflectors for optical tracking from ground.


Equipped with LEDs (Light Emitting Diodes) and retroreflectors for optical tracking with ground-based telescopes and laser ranging observatories. Testing orbit and attitude determination by means of ground based optical observation and testing LED based optical communication.

LEDSAT will equip a bespoke digipeater system with both real tile and “store & forward” capabilities for radio-amateur use; the radio-amateur user can define the delay in the retransmission of the message in a range of 0sec to 24hours.


The CubeSat switched on successfully after the deployment and all the parameters received through the telemetry were nominal. The LEDs payload was successfully switched on and observed by the S5Lab optical ground station network just 3 days after the deployment, proving the capability to detect the LEDs from ground.

Sources [1] [2] [3] [4] [5] [6] [7] [8]
Photo sources [1] [2] [3] [4]
COTS subsystems
  • SOLAR PANELS - GomSpace
Subsystems sources [1]
On the same launch
